SPIDAR®
Gallery
Multiple frequency, pulseEKKO PRO 500 and 200
used for shallow utilities and deeper geological structure – Toronto, Canada
Multiple frequency,
pulseEKKO PRO 500 and 1000 used for pavement forensics – Toronto, Canada
Multiple channels 3
pulseEKKO PRO 500 systems used for archaeology surveys – Ghent, Belgium
Multiple channels, 3 Noggin
500 systems used for sewer investigations – Hamilton, Canada
Multiple channels, 4 Noggin
250 systems used for quickly mapping drainage pipes – Iowa, USA
Multiple channels, 7 Noggin
1000 systems used for quickly mapping large areas of concrete – Toronto, Canada
Multiple polarization,
pulseEKKO PRO 500 used for soil properties – Toronto, Canada
Multiple frequency,
Noggin 250 and 500 mapping shallow and deeper utilities – Toronto, Canada
Multiple channels
6 pulseEKKO PRO 500 systems – Ludwig Boltzman Institute large scale archaeology
Multiple frequency
pulseEKKO PRO 500 and 1000 introduced at GPR 2010 – Lecce, Italy
Multiple frequency
pulseEKKO PRO 500 and 100 used for concurent collection of ice thickness, bathymetry and sub-bottom stratigraphy – Barrie, Canada
Multi-channel Array System:
SmartCart with 3 Noggin 250 systems for utility-locating
Multi-channel Array System:
SmartCart with 2 Noggin 250 systems for utility-locating
Case Studies
Bathymetric survey | Sub Bottom Profiler GPR
Hydrologists and engineers often require accurate water depth and information about sub-bottom stratigraphy in shallow freshwater lakes and rivers. Uses can vary from estimating available water volumes to the engineering design of new structures.
